16+
4‑Stroke, Air‑Cooled, Single‑Cylinder
Limited Warranty
Top Speed
(CVT) Transmission
SPECIFICATIONS
| Engine Type: | 4-Stroke,Air cooled(GY6) |
| Displacemen: | 168CC |
| Compression ratio: | 9.5:1 |
| Cylinder Diameter: | 61mm |
| Piston stroke: | 57.8mm |
| Transimission: | CVT automatic |
| Ignition method: | CARBURETOR |
| L x W x H: | 1910x720x1150mm |
| Wheel base: | 1300mm |
| Wet Weight: | 110KG |
| Max Loading weight: | 150kg |
| Brake / Front: | Disc |
| Brake / Rear: | Disc |
| Tires / Front: | 130/60-13 |
| Tires / Rear: | 130/60-13 |
| Suspension/Front: | Telescopic |
| Suspension/Rear: | Spring hydraulic |
| Fuel Capacity: | 5L |
| Fuel consumption: | 2.4(L/km) |
| Max.speed: | 100(km/h) |
| Max Power: | 6.8 (kw/rpm) |
| Max Torque: | 9.3 (N.m/rpm) |
| Rpm: | 1600±100 |
| Seater Hight | 80cm |
| Ground clearence | 11cm |
| 40HQ Loading QTY : | 78pcs(SKD) |
| Accessories | USB，Bluetooth ,Rear Basket |
