Description
SPECS
| carburetor | PZ19 |
| engine Brand | FH |
| engine | 110cc Air cooled, Fully automatic |
| Engine Gear | Fully automatic |
| Transmission | Chain Drive |
| Engine Bore X Stroke | 52.4×49.5mm |
| compression ratio | 9：1 |
| max power | 6.7HP/7500r/min |
| Max torque | 7.2N.m/7500 r/min |
| Ignition | CDI |
| Engine Oil total capacity | 0.24 Gallon |
| Fuel Tank Capacity | 0.85 Gallon |
| Start way | Electrical Start |
| Front wheel | 60/100-14 |
| Rear wheel | 80/100-12 |
| Drive train | Chain drive |
| Front absorber | 320mm Non-Adjustable |
| Rear absorber | 260mm Non-Adjustable |
| Front Hand Brake | Hydraulic Disc |
| Rear Foot Brake | Hydraulic Disc |
| Frame | Single beam Heavy Duty Steel fram |
| N.W: | 142 LBS |
| G.W | 160 LBS |
| Products size(L*W*H) | 61*30*35 inches |
| seat high | 30 inches |
| Ground Clearance | 8 inches |
| box size(L*W*H) | 49*15*25.6inches |
