Specifications:

Brakes Front and Rear Disc Wheels 2.5×10 front and 7×12 Rear

Tires 120/90/10 Front and 235/30/12 Rear

DIMENSIONS

Wheelbase62″

Seat Height 26″

DRIVETRAIN

Transmission auto Drive System Belt

ELECTRICAL

Battery 12V7A

Instrumentation analog

ENGINE

Cooling air Cylinders 1

Horsepower 10 Displacement 149cc

Fuel System carb Ignition CDI

Lubrication 10W/40 engine oil and GL4 gear oil Fuel Capacity 1.1 gallons

OPERATIONAL

Maximum Speed 55 mph Maximum Load 555 lbs
