Model No

ENGINE INFO

Engine type:

Single-cylinder, 4-stroke, horizontal type, air-cooled

Displacement(ml):

169

Max Power(kw/r/min):

7.0/7500

Max Torque(N.m/r/min):

9.5/6000

Ignition system:

CDI

Gear :

CVT(F+N+R)

Fuel tank capacity(L):

10

Economical oil exhaust(L/100km):

4.5

Max speed(km/h):

50

Transmission:

Belt Drive and Chain Drive

Brake Type(front / rear):

Disc / Disc Brake

Wheelbase(mm):

1760

Ground clearance(mm):

200

Tires (Front/Rear):

21*7-10 / 22*11-10  (With Extra spare tire)

N. W.(kg):

240     G. W.(kg): 300

Product dimension(mm):

2335*1460*1505

Carton dimension(mm):

Crate dimension(Inches)/Weight(LBS):

2370*1140*820

93″X45″X26″    675LBS
