16+
125cc, 154FMI, XinYuan
Limited Warranty
Top Speed
(CVT) Transmission
Specifications
| Engine | 125cc, 154FMI, XinYuan |
| Transmission | 3-speed with reverse |
| Drive type | Chain |
| Belt and or chain size | Chain: 530H 153L |
| Starter System | Electric |
| Fuel system | Gasoline, 1.06gal, carbureted |
| Brake (Front/Rear) | Disc/Disc |
| Tire size(Front/Rear) | 18×7-8 |
| Wheel size and type(Front/Rear) | 8, Steel |
| Oil capacity and type (in liters) | 0.8L, Air cooled motorcycle oil with clutch additive |
| Gear oil type and capacity (in liters) | N/A |
| Battery | 12V9A |
| Light | Standard Lights |
| Suspension(Front/Rear) | dual A-arms front. swingarm rear |
| Dimensions (in inch) | Assembled(LxWxH): 78.74×35.43×29.13, Seat Height: 23.62, Wheelbase:51.18 |
| Weight(net/gross/capacity) | 330.7/363.8 lbs. |
| weight capacity | 264.6 lbs. |
| Ground Clearance (in inch) | 9.84 |
| Assembly Require | Front and rear wheels, windshield, steering column, seat, spare tire holder, gas can holder, seat bars, seat belts, battery |
| Any special features | Include: windshield, spare tire, gas can |
| EPA/carb approved | EPA Approve |
